Description
DMC776 EMB-120 BRASILIA MAINTENANCE KIT For Electrical Connectors and Wiring Systems
THE MAINTENANCE PROBLEM…
Modern aircraft, such as the EMB-120 BRASILIA, have complicated? electrical wiring systems containing many different connectors, contacts and terminals, the repair of which require precision tools. It is not a cost effective use of the time of your technical staff to start from scratch and try to become intimately knowledgeable about which precision tools must be used to repair each electrical connector, contact and terminal when DMC has already performed this task for the EMB-120 BRASILIA.
AOG TIME CONSTRAINTS.
Once the aircraft becomes inoperable because of a connector failure, it is imperative to be able to replace the connector, contact or terminal as quickly as possible to avoid revenue loss due to AOG. The DMC776 kit supplies your staff with both the information and the tools necessary to make this type of repair to the
EMB-120 BRASILIA in the shortest time possible.
THE DMC SOLUTION…
TOOLING RESEARCH.
DMC has already researched the list of connectors for the EMB-120 BRASILIA and has identified the most common tools required to maintain the electrical connectors in the EMB-120 BRASILIA. DMC has cross referenced these tools to the connectors, contacts and terminals, eliminating costly and time-consuming research which would otherwise have to be performed by your electrical technicians.
IMMEDIATE AVAILABILITY OF TOOLS?AND TECHNICAL INFORMATION.
The?DMC776 kit contains all of the tooling to connector, contact and terminal cross reference information needed to support the EMB-120 BRASILIA. In addition, the DMC776 kit also contains illustrated operating instructions for the required tooling. ALL IN ONE. Since all of these tools, together with their operating instructions, are contained in a single kit, the connector repair can be made in the shortest time possible, thus permitting a rapid return of your EMB-120 BRASILIA to service.
DMC776 TOOL AND ACCESSORY LIST
6 Crimp Tools
3 Turret Heads
5 Positioners
8 Metal Insertion Tools
10 Metal Removal Tools
55 Plastic Ins/Rem Tools
4 Contact gages
2 Unwired Contact Removal Tools w/ Probes
1 In-Service Inspection Gage
1 Die Removal Tool
1 Die Set
1 Hex Wrench
1 Wire Harness Spoon
DMC776 CONNECTOR COVERAGE
MANUFACTURER?SERIES
AMP Mate-N-Lock, MR Series
Amphenol RF RF Coaxial
Bendix ECD PT Series
Collins Radio Thin-Line, Pro-Line Series
Deutsch DM Series
ITT Cannon D*C, DPXMA, DPXB, DPXNE
Leach Relays J, JL, K Relay Sockets
Matrix Science MB Series
Molex Rectangular Series
Souriau 851 Series
MIL-C-24308 Rectangular Rack and Panel
MIL-C-26482 Series 1, 2
MIL-C-38999 Series 1, 2
MIL-C-5015 3450 Series
MIL-C-81659?Series 2
MIL-C-83723 Series 3
MIL-R-6106 Relay Sockets
TOOL KIT CONFIGURATION
Type of Case:?Portable
Number of Cases:?1
Colour:?Yellow
Type of Construction: Fiberglass/Aluminum
Application:?EMB-120 BRASILIA
Coverage:?Airframe Power Connectors, Terminals size 12 AWG?and Smaller,?Coaxial Connectors
Type of Inserts:?Unicellular Polyethylene Foam with Die Cut Tool Cavities
