Description
Modern aircraft, such as the Challenger 300/350, have complicated electrical wiring systems containing many different connectors, contacts and terminals, the repair of which require precision tools.
It is not a cost effective use of the time of your technical staff to start from scratch and try to become intimately knowledgeable about which precision tools must be used to repair each electrical connector, contact and terminal when DMC has already performed this task for the Challenger 300/350.
AOG TIME CONSTRAINTS.
Once the aircraft becomes inoperable because of a connector failure, it is imperative to be able to replace the connector, contact or terminal as quickly as possible to avoid revenue loss due to AOG. The DMC2232 kit supplies your staff with both the information and the tools necessary to make this type of repair to the Challenger 300/350 in the shortest time possible.
THE DMC SOLUTION…
TOOLING RESEARCH.
DMC has already researched the list of connectors for the Challenger 300/350 and has identified the most common tools required to maintain the electrical connectors in these aircraft. DMC has cross referenced tools to the connectors, contacts and terminals eliminating costly and time-consuming research which would otherwise have to be performed by your local technicians.
IMMEDIATE AVAILABILITY OF TOOLS AND TECHNICAL INFORMATION.
The DMC2232 kit contains all of the tooling to connector, contact and terminal cross reference information needed to support the Challenger 300/350. In addition, the kit also contains illustrated operating instructions for the required tooling.
ALL IN ONE.
Since these tools, together with their operating instructions, are contained in three, environmentally sealed, polypropylene cases, the connector repair can be made in the shortest time possible, thus permitting a rapid return of your aircraft to service. Tool kit includes: Name Plate, Foam Pads/Inserts, Contents Charts, Instruction Charts, and Tool Selection Charts.
| DMC2232 TOOL AND ACCESSORY LIST | |
| 9 | Crimp Tools |
| 3 | Turret Heads |
| 15 | Positioners |
| 3 | Single Position Heads |
| 13 | Metal Insertion Tools |
| 17 | Metal Removal Tools |
| 1 | Metal Insertion/Removal Tool |
| 51 | Plastic Ins/Rem Tools |
| 4 | Contact gages |
| 3 | Unwired Contact Removal Tools |
| w/ Probes | |
| 1 | Wire Cutter |
| 2 | Wire Strippers |
| 6 | In-Service Inspection Gages |
| 1 | Die Removal Tool |
| 21 | Die Sets |
| 1 | Hex Wrench |
| 3 | Coaxial Cable Stripper |
| 1 | X-Acto Knife |
| 1 | Heat Gun |
| 1 | Reflector Nozzle (9mm) |
| 1 | Reduction Nozzle (9mm) |
| 1 | Wire Harness Spoon |
| 2 | Module Removal Tools |
| DMC2232 CONNECTOR COVERAGE | |
| MANUFACTURER | SERIES |
| MIL-C-5015 | Series “3450” |
| MIL-C-24308 | D-Summiniature |
| MIL-C-26482 | Series I, II |
| MIL-C-26500 | Firewall Connectors |
| MIL-C-38999 | Series I, II, III |
| MIL-C-81659 | Arinc 404 |
| MIL-C-83723 | Series III |
| MIL-S-12883 | Relay Sockets |
| MIL-T-7928 | Insulated Splices |
| MIL-T-81714 | Terminal Junctions |
| Amphenol Aerospace | CTV, T3F |
| Amphenol RF | SMA Plugs |
| ECS | SMA and TNC Plugs |
| Emteq | ARINC 600, TNC Plugs |
| Hi-Rel | 86000Y Series |
| ITT Cannon | BKA, DCMA, DPX*MA, KPSE Series |
| Kidde/Fenwal | Fire Detection Connectors |
| Positronic | RD Series |
| Radiall | NSX Series |
| Rockwell Collins | Thin-Line Series |
| Souriau | 853 Series |
| TE Connectivity | Amplimite, .187 Series, CPC, PIDG Series, Solistrand Series, Stratotherm Series, D-436 Series |
| Times Microwave | TNC Plugs |
| T & B | Sta-Kon Terminals |
| TOOL KIT CONFIGURATION | ||
| Type of Case | Portable/Environmental | |
| Number of Cases | 3 | |
| Color | Yellow | |
| Type of Construction | Polypropylene | |
| Application | Challenger 300/350 | |
| Coverage | Airframe Power Connectors | |
| Terminals size 12 AWG and Smaller | ||
| Coaxial Connectors | ||
| Type of Inserts | Unicellular Polyethylene | |
| Foam with Die Cut Tool Cavities | ||
