DMC1293 WIRING SYSTEM SERVICE KIT For the LEARJET 45
THE MAINTENANCE PROBLEM…
Modern aircraft, such as the LEARJET 45, have complicated electrical wiring systems containing many different connectors, contacts and terminals, the repair of which require precision tools.
It is not a cost effective use of the time of your technical staff to start from scratch and try to become intimately knowledgeable about which precision tools must be used to repair each electrical connector, contact and terminal when DMC has already performed this task for the LEARJET 45.
AOG TIME CONSTRAINTS. Once the aircraft becomes inoperable because of a connector failure, it is imperative to be able to replace the connector, contact or terminal as quickly as possible to avoid revenue loss due to AOG. The DMC1293 kit supplies your staff with both the information and the tools necessary to make this type of repair to the LEARJET 45 in the shortest time possible.
THE DMC SOLUTION…
TOOLING RESEARCH.
DMC has already researched the list of connectors for the LEARJET 45 and has identified the most common tools required to maintain the electrical connectors in the LEARJET 45. DMC has cross referenced tools to the connectors, contacts and terminals eliminating costly and time-consuming research which would otherwise have to be performed by your local technicians.
IMMEDIATE AVAILABILITY OF TOOLS AND TECHNICAL INFORMATION.
The DMC1293 kit contains the tooling to connector, contact and terminal cross reference information which indicate the particular tool(s) that should be selected to repair a specific connector, contact, or terminal. In addition, the kit also contains illustrated operating instructions for the required tooling.
ALL IN ONE. Since these tools, together with their operating instructions, are contained in a single kit, the connector repair can be made in the shortest time possible, thus permitting a rapid return of your aircraft to service. Tool kit supplied in 2 environmentally sealed fiberglass cases and includes: Name Plate, Foam Pads/Inserts, Contents Charts, Instruction Charts, and Tool Selection Charts.
DMC1293 TOOL AND ACCESSORY LIST
9?Crimp Tools
5?Turret Heads
11 Positioners
1 Single Position Heads
1 Universal Turret Head
1 Universal Positioner
8 Die Sets
11 Metal Insertion Tools
11 Metal Removal Tools
1 Metal Ins/Rem Tools
58?Plastic Ins/Rem Tools
4 Contact gages
2 Unwired Contact Removal Tools w/ Probes
1 Wire Cutter
2 Wire Strippers
2 In-Service Inspection Gage
1 Die Removal Tool
1 Hex Wrench
1 Wire Harness Spoon
4 Coaxial Cable Stripper
DMC1293 CONNECTOR COVERAGE
MANUFACTURER SERIES
AMP Termashield, M, CPC Series, In-Line Splices
Channel/Air LB Terminal Junctions
Edison Fire Detection Connectors
Deutsch 724 Series
Kings Electronics RF Coaxial
Positronics SD Series
Raychem Environmental Splices
Souriau 8525 Series
MIL-C-26482 Series 1 & 2
MIL-C-38999 Series 1, 2 & 3
MIL-C-5015 3450 Series
MIL-T-81714 Terminal Junctions
MIL-T-7928 Insulated/Uninsulated Terminals/Splices
TOOL KIT CONFIGURATION
Type of Case:?Portable
Number of Cases:?2
Colour:?Yellow
Type of Construction: Fiberglass/Aluminum
Application:?LEARJET 45
Coverage:?Airframe Power Connectors,?Terminals size 12 AWGand Smaller, Coaxial Connectors
Type of Inserts: Unicellular Polyethylene Foam with Silhouetted Tool Cavities
