DMC1246 MAINTENANCE KIT For Electrical Connectors and Wiring Systems
THE MAINTENANCE PROBLEM…
Modern aircraft, such as the Cessna Citation X, have complicated electrical wiring systems containing many different connectors, contacts and terminals, the repair of which require precision tools. It is not a cost effective use of the time of your technical staff to start from scratch and try to become intimately knowledgeable about which precision tools must be used to repair each electrical connector, contact and terminal when DMC has already performed this task for the Citation X.
AOG TIME CONSTRAINTS
Once the aircraft becomes inoperable because of a connector failure, it is imperative to be able to replace the connector, contact or terminal as quickly as possible to avoid REVENUE LOSS/LOSS OF MISSION CAPABILITY due to AOG. The DMC1246 kit supplies your staff with both the information and the tools necessary to make this type of repair to the Citation X in the shortest time possible.
THE DMC SOLUTION…
TOOLING RESEARCH.
DMC has already researched the list of connectors for the Citation X and has identified the most common tools required to maintain the electrical connectors in the Citation X. DMC has cross referenced these tools to the connectors, contacts and terminals, eliminating costly and time-consuming research which would otherwise have to be performed by your electrical technicians.
IMMEDIATE AVAILABILITY OF TOOLS AND TECHNICAL INFORMATION.
The DMC1246 kit contains all of the tooling to connector, contact and terminal cross reference information needed to support the Citation X. In addition, the DMC1246 kit also contains illustrated operating instructions for the required tooling.
ALL IN ONE.
Since all of these tools, together with their operating instructions, are contained in a single kit, the connector repair can be made in the shortest time possible, thus permitting a rapid return of your Citation X to service.
DMC1246 TOOL AND ACCESSORY LIST
12? Crimp Tools
7 Turret Heads
9 Positioners
1 Single Position Head
1 Universal Positioner
1 Universal Turret Head
5 Die Sets
18 Metal Insertion Tools
19 Metal Removal Tools
88 Plastic Ins/Rem Tools
4 Contact gages
2 Unwired Contact Removal Tools w/ Probes
1 Wire Cutter
4 Wire Strippers
6 In-Service Inspection Gage
1 Die Removal Tool
1 Hex Wrench
3 Coaxial Cable Stripper
1 Cable Tie Tool
2Module Removal Tools
300 Sealing Plugs
DMC1246 CONNECTOR COVERAGE
MANUFACTURER?SERIES
MIL-C-24308?Rectangular
MIL-C-25516 RF Coaxial
MIL-C-26482 Series 1 & 2
MIL-C-38999 Series 2 & 3
MIL-C-5015 3100 & 3400 Series
MIL-C-81659 Arinc 404
MIL-C-83723 Series 1 & 3
MIL-S-81824 Environmental Splices
MS25036?Insulated Terminals
MS20659 Uninsulated Terminals
AMP Metrimate, Universal Mate-N-Lok, Commercial Mate-N-Lok, M Series, PIDG, Solistrand, Strato-Therm, Insulated/Uninsulated Terminals and Splices, Fuel Quantity Probe Terminals
Appleton Electric Relays and Relay Sockets
Deutsch DS, RE04, RE54, CTS Series, Jiffy Junctions
DME Disconnects and Environmental Splices
ITT Cannon?D*MA Series
Kings Electronics RF Coaxial
Leach Relays and Relay sockets
Positronics?GMCT Series
Pyle-National?LMD/LMS Series
Raychem Environmental Splices
Thomas & Betts Fuel Quantity Probe Flag Terminals
TOOL KIT CONFIGURATION
Type of Case?Portable with Tray
Number of Cases 2
Color Yellow
Type of Construction Fiberglass/Aluminum
Application Cessna Citation X
Coverage Airframe Power Connectors, Terminals size 12 AWG and Smaller,?Coaxial Connectors
Type of Inserts Unicellular Polyethylene Foam with Die Cut Tool Cavities
